1－14
JMA-9100/7100 Installation Manual > 1.EQUIPMENT COMPOSITION > 1.2 LIST OF CIRCUITS
Table1-15： JMA-7122-6XA/JMA-7122-9XA SCANNER UNIT
NKE-1125-61,NKE-1125-91 NKE-1125-62,NKE-1125-92
SCANNER
UNIT
SCANNER UNIT
INTERCONNECTION
CAX-11
SAFETY SWITCH CSD-654
ENCODER CHT-71A
MOTOR MDBW10822
AC100V MOTOR DRIVER
7EPRD0035
AC220VMOTOR DRIVER
7EPRD0034
BREAKCIRCUIT CFA-253
BREAK CONTROL CIRCUIT
CCB-655
BREAK UNIT NZR-16
MODULATOR UNIT NMA-550-1
MODULATOR UNIT
INTERCONNECTION
CMB-404
MODULATORCIRCUIT CPA-264
MAG FILTER CIRCUIT CFR-229
RECEIVER UNIT NRG-162A
RECEIVERCIRCUIT CMA-866A
T/R CONTROL CIRCUIT CMC-1205R
RELAY FILTER CIRCUIT CSC-656
POWER SUPPLY CIRCUIT
CBD-1682A
HEATER CONTROL PART
CHG-216
PERFORMANCE MONITOR
NJU-85
DISPLAY
UNIT
NCD-4790/T
