JMA-9100/7100 Installation Manual > 1.EQUIPMENT COMPOSITION > 1.2 LIST OF CIRCUITS
1－17
1
Table1-18： NCD-4790/NCD-4790T DISPLAY UNIT
NCD-4790 NCD-4790T
RADAR PROCESS
UNIT
NDC-1399-7 NDC-1399-7
RADAR PROCESS
CIRCUIT
CDC-1324
AIS PROCESS
CIRCUIT
CDC-1325
ARPA PROCESS
CIRCUIT
CDC-1186D
GYRO I/FCIRCUIT CMJ-462E
MOTHER BOARD CQC-1192
TERMINAL
BOARD CIRCUIT
CQD-2097
POWER SUPPLY CBD-1661
RADAR PROCESS
UNIT
INTERCONNECTION
CML-763
RADAR PROCESS
UNIT
INTERCONNECTION
CML-763T
OPERATION
UNIT
NCE-5163 NCE-5163
OPERATION
CIRCUITＡ
CCK-973
OPERATION
CIRCUITＢ
CCK-974
OPERATION
CIRCUITＤ
CCK-976
OPERATION UNIT
INTERCONNECTION
CMD-996-R
OPERATION UNIT
INTERCONNECTION
CMD-996-RT
MONITOR UNIT NWZ-173 NWZ-173
AC-DC
CONVERTER
NBA-5135 *(Only for NKE-2103-6/6HS,NKE-2254-6/6HS)
