JMA-9100/7100 Installation Manual > 3.INSTALLATION OF DISPLAY UNIT > 3.2 INSTALLATION OF AC-DC CONVERTER NBA-5135
3－15
3
Fig 3-13: Equipment 3 of NBA-5135 (NCD-4990)
Fig 3-14: Equipment 4 of NBA-5135 (NCD-4990)
Fig 3-15: Equipment 5 of NBA-5135 (NCD-4990)
４．NBA-5135の取り付け
Mount the NBA-5135 by
using five screws.
←手前/front 5-M5 奥/rear→
U
奥側/REAR SIDE
U
手前側/FRONT SIDE
