23
◎ Audio output attenuation (XLR)
At oFF No attenuation at audio output
At on 20dB attenuation at audio out-
put (depending on whether the
transmitter is provided with the
corresponding function) .
The function is activated with 20dB of audio
output attenuation.
◎ SQ Receiving sensitivity
-5~+10dB; select
SQ with ▲/▼
-5 is the maximum
sensitivity.
+10 is the minimum
sensitivity.
The default setting is 0.
It shows the SQ is 0dB (default setting).
When TX transmitter is selected:
◎ ATT microphone audio input attenuation
At oFF No attenuation at audio input
At on 20dB attenuation at audio input
(Only for RU-850LTB.)
This function is deactivated.
◎ Microphone input sensitivity
Normal
sensitivity
GAIN：+15dB
GAIN：+12dB
GAIN：+9dB
GAIN ：+6dB
GAIN：+3dB
GAIN：0dB
GAIN：-3dB
GAIN：-6dB
GAIN：-9dB
GAIN：-12dB
GAIN：-15dB
It shows the microphone input sensitivity is now
at 0dB (default setting).
