Visually inspect your shipping box and the e-bike to see that
everything arrived without shipping issues. Take pictures if you
suspect excessive rough handling and contact
support@juicedbikes.com.
Watch our assembly videos and feel free to invite a handy
friend. Call us with any assembly quesons. Also, you can e-mail
support@juicedbikes.com and we can send you more specic
informaon. We oen generate new user guides based on the
feedback we receive from our customers.
Charge the baery pack. See “Charging the Baery Pack” on
page 30.
NOTICE
The kickstand is designed to support the e-bike only. Do not sit on the e-bike with
the kickstand engaged. Sitting on the e-bike with the kickstand engaged could result
in damaged to the kickstand.
NOTICE
The front wheel must be inspected before every ride to ensure it is securely attached
to the bike. Failure to test that the front wheel is properly secured could result in
signicant injury or even death.
INSTALLING THE FRONT WHEEL
Remove the shipping spacer, bolt and nut from the front wheel
fork.
1. Remove the spacer between the front disc brake caliper.
Do not squeeze the front brake handle. Squeezing the front
brake handle will cause the pads to move and it may be
dicult to posion the front brake disc within the pads.
Fig. 10 - Removing Shipping Spacer
3 ASSEMBLY
2. Insert the axle into the front wheel hub. Posion the wide
spacer (chain drive side) and slim spacer (disc brake side)
on the axle. Insert the front wheel in between the forks
while posioning the front brake disc in the brake caliper.
Spacers must be in between the forks.
3. Place a washer onto the axle on the outside of the forks.
Fig. 11 - Installing the Front Wheel
4. Install and hand-ghten the two adjustment nuts equally.
Use the supplied 15 mm socket and 15 mm wrench to
nish ghtening the adjustment nuts, being sure each nut
is ghtened equally on both sides.
5. The adjustment nuts must be very ght; be sure to
reghten them aer your rst two rides.
INSTALLING THE HANDLEBARS
1. Point the headset towards the front of the bike.
2. Center the handlebar in the headset, taking care not to
damage any wires.
3. Install the clamp and screws. Alternately ghten the screw
side-to-side unl secure.
4. Verify that the front re lines up with the headset.
5. Verify that all headset items are ght.
Fig. 12 - Installing the Handlebars
