USB Port – This feature is located on the le-side handlebar.
Fig. 9 -
USB Port
Charger - The charger plugs into the electrical outlet. It
energizes the baery pack as needed. The more energy that is
discharged from the baery pack, the longer the charger will
take to recharge.
GENERAL INFORMATION
ELECTRONIC MODULES SPECIFICATIONS
Top Speed 30+ mph
Range 40-100 miles*
Weight 102 lbs with battery (90 lbs without battery)
Battery Pack 52 VDC Battery/19.2 Ah extended range
Charge Time 5-7 hours
Headlight 1,050 lumens
Tires
20 in. x 4.25 in. wide. Inate to psi indicated on
tire
Weight Capacity 275 lbs
* See “Understanding the Baery Pack Range” on page 19.
