NOTICE
The kickstand is designed to support the e-bike only. Do not sit on the e-bike with
the kickstand engaged. Sitting on the e-bike with the kickstand engaged could result
in damaged to the kickstand.
NOTICE
The front wheel must be inspected before every ride to ensure it is securely attached
to the bike. Failure to test that the front wheel is properly secured could result in
signicant injury or even death.
INSTALLING THE FRONT WHEEL
(MAG WHEEL BIKES)
Remove the shipping spacer, bolt and nut from the front wheel
fork.
1. Remove the spacer between the front disc brake caliper.
Do not squeeze the front brake handle. Squeezing the front
brake handle will cause the pads to move and it may be
dicult to posion the front brake disc within the pads.
Fig. 10 - Removing Shipping Spacer
3 ASSEMBLY
2. Insert the axle into the front wheel hub. Posion the wide
spacer (chain drive side) and slim spacer (disc brake side)
on the axle. Insert the front wheel in between the forks
while posioning the front brake disc in the brake caliper.
Spacers must be in between the forks.
3. Place a washer onto the axle on the outside of the forks.
Fig. 11 - Installing the Front Wheel
4. Install and hand-ghten the two adjustment nuts equally.
Use the supplied 15 mm socket and 15 mm wrench to
nish ghtening the adjustment nuts, being sure each nut
is ghtened equally on both sides.
5. The adjustment nuts must be very ght; be sure to
reghten them aer your rst two rides.
INSTALLING THE FRONT WHEEL
(SPOKE WHEEL BIKES)
Remove the shipping spacer, bolt and nut from the front wheel
fork.
1. Remove the spacer between the front disc brake caliper.
Do not squeeze the front brake handle. Squeezing the front
brake handle will cause the pads to move and it may be
dicult to posion the front brake disc within the pads.
Fig. 12 - Removing Shipping Spacer
2. Insert the front wheel in between the fornt fork on the
bike. Be sure the fork is resng on the outside of the axle.
ASSEMBLY
