FEATURES
An e-bike is similar to a normal bicycle. The major dierence is
the addion of an electric motor that provides a boost when
desired. An onboard rechargeable lithium baery pack supplies
the motor with electric power. Users can ride the bicycle using
both pedal power and baery pack power at the same me.
The controller regulates how much power the battery pack
sends to the motor. The controller is located under the seat.
Fig. 1 -
Controller
Throttle - The throle allows the rider to ride the bike & control
the bike’s speed without pedaling. It sends a signal to the
controller telling it how much power to send to the motor. The
throle is located on the right handlebar.
Fig. 2 -
Throle
2 GENERAL INFORMATION
Battery Pack - The baery pack stores electrical energy. It is
composed of many smaller baery pack cells that act similar to
that of a modern mobile phone.
Fig. 3 -
Baery Pack
LCD Display - The display reads the baery pack’s voltage. This
will provide an esmate of the baery pack’s charge state. The
display may have other buons to control other funcons.
Fig. 4 - LCD Display
