Output Connection
Output Signal
The output of the juicedLink is an amplified mic level signal. The juicedLink is not intended to drive line level
signals. It is not necessary to have a lot of gain to interface with a camcorder. You want just enough gain to be
able to throttle back the noisy camcorder amplifiers, to yield improved signal-to-noise performance while recording
fine audio detail. To much gain would overload the camcorder.
Connection to Camcorder
Connect the plug from one end of the shielded cable to the OUT 3.5mm stereo jack on the mixer. Connect the plug
from the other end of the cable to the camcorder’s microphone input jack. The camcorder’s integrated microphone
will now be disabled.
Some camcorder microphone input jacks supply low voltage DC for powering external microphones. Therefore, the
mixer output driver has been protected from external voltages with DC blocking capacitors. Large capacitance
values have been selected to provide excellent low frequency response.
Connection to Recorders, Computers, etc.
The output of the juicedLink can be connected to any recording device expecting stereo minijack mic level signals.
