juicedLink CX211 - Mounting; Positioned under Camcorder; Rotation Secured with Azimuth Pin; Rotated Position - Unsecured

Page 16 www.juicedLink.com
Mounting
Positioned Under Camcorder
Rotation Secured with Azimuth Pin
Align the azimuth pin and mounting screw on top of the mixer, with the corresponding holes on the bottom of the
camcorder. Use the 1/8” hex key (provided) to tighten the mounting screw. Check to make sure that the
connection is tight enough, and the azimuth pin is constraining rotation between the two.
Rotated Position – Unsecured
There may be circumstances where you wish to have the XLR connectors and cables protruding from your setup in
a different orientation from the one secured from the azimuth pin. The azimuth pin may be removed, providing
freedom of rotation. Only use this configuration while you are shooting and holding the camcorder itself with your
hands.
WARNING - PHYSICAL DAMAGE TO YOUR EQUIPMENT SET MAY RESULT IF YOU USE THE TRIPOD
MOUNT ON THE BOTTOM OF THE MIXER TO SECURE YOUR EQUIPMENT SET, AND THE CAMERA IS
MOUNTED TO THE MIXER WITHOUT SECURING THE ROTATION BY USING THE AZIMUTH PIN.
Mounted to Tripod
First, follow the directions to mount the camera to the top of the mixer. Make sure that the rotation is secured with
the azimuth pin.
Next, align the azimuth pin and screw from the tripod head with the holes on the bottom of the mixer, and tighten.
Make sure that the rotation at this point is also secured by the tripod head azimuth pin.
WARNING - PHYSICAL DAMAGE TO YOUR EQUIPMENT SET MAY RESULT IF YOU USE THE TRIPOD
MOUNT ON THE BOTTOM OF THE MIXER TO SECURE YOUR EQUIPMENT SET, AND THE CAMERA IS
MOUNTED TO THE MIXER WITHOUT SECURING THE ROTATION BY USING THE AZIMUTH PIN.
Other Positions – Shoulder Strap
The aluminum enclosure has the facilities for other methods of attachment, for example, a shoulder strap. If the
strap attachments are too large to fit in the holes, then attach a key-ring like device to make attachment holes large
enough.
Use of a shoulder strap is preferred to use of a belt clip. With a belt clip, you will have heavy microphone wires
tugging at your belt. You don’t want to be distracted and miss the shot because you were pulling up your pants.
We have not included a shoulder strap in the package. More customers are mounting to the camera. Also,
customers that do want to use a shoulder strap are particular about length and width, etc.
