Page 6 www.juicedLink.com
Panel Descriptions
FRONT
1
3
4
5
6
7
8
9
10
11
11
2
1) POWER SWITCH
2) “ON” LED INDICATOR
3) LOW BATTERY INDICATOR
4) PREAMPLIFIER GAIN SETTINGS
5) TRIM POTENTIOMETERS
6) AUDIO METER DISPLAY (RIGHT/LEFT)
Not available on all models.
7) AUDIO METER POWER SWITCH
Not available on all models.
8) XLR INPUTS
9) UNDER-CAMERA ATTACH SCREW
10) AZIMUTH PIN (removable)
11) SHOULDER STRAP CONNECTION POINTS
Shoulder strap not included.
