Camcorder XLR Adapter/Preamp/Mixer User’s Manual Page 3
Read This First
Before operating the unit, please read this manual thoroughly.
Although there are numerous combinations of settings for the mixer gain plus recording device gain (camcorder)
that will result in the identical signal levels, they will have different characteristics in terms of noise and dynamic
range. This manual provides guidelines and practices to yield the best overall signal purity.
Any future revisions will be posted on the website and available for download.
Some of the features described in various sections may not be available on your model. Please refer to the
Feature Comparison Chart to determine the capabilities of your particular device.
Notes regarding documentation in this manual are as follows:
- References to markings/labels on the unit are denoted in underline/bold. For example: HPF.
- Warnings will be preceded with WARNING.
Warnings - General
WARNING: Failure to read and observe notes and warnings may result in personal injury, and/or possible damage
to this device and your other equipment.
WARNING - LOSS OF HEARING: Although headphones do not plug directly into this mixer, it is common for
headphones to be used with other equipment to monitor the audio signal transmitted by the mixer. The devices
that are driving the headphones, such as camcorders, are often capable of driving the signal at levels that can be
damaging to hearing. Always operate the headphone volume at the lowest practical level. Do not wear the
headphones over your ears in any of the following circumstances:
- While plugging the headphones into the headphone driving device.
- While plugging the mixer into the headphone driving device.
- While turning on or off the mixer.
- While turning on or off the phantom power.
- While plugging a device into the input of the mixer.
WARNING - RISK OF ELECTRICAL SHOCK: This device, its enclosure, and the connections to cable shields that
plug into this device are conductive. Avoid electrocution and observe caution with cable runs near areas where
high-voltages and/or currents may exist.
Checking Supplied Items
Your package should include the following items:
- Ultra-Portable Mixer model that you purchased.
- 9-inch cable with stereo male 3.5mm plugs on each end.
- 1/8 inch hex key
- Quick Start Guide
To Next Page
