1. SPECIFICATIONS
!
. MECHANICAL SECTION (WITH REGARD TO THE SEWING MACHINE)
1 Sewing area X (lateral) direction Y (longitudinal) direction
AMS-210EN-1306
: 130 mm ×
60 mm
AMS-210EN-1510
: 150 mm ×
100 mm
AMS-210EN-2210
: 220 mm ×
100 mm
2 Max. sewing speed 2,800 sti/min (When sewing pitch is 4 mm or less)
3 Stitch length 0.1 to 12.7 mm (Min. resolution : 0.05 mm)
4
Feed motion of feeding frame
Intermittent feed (2-shaft drive by stepping motor)
5 Needle bar stroke 41.2 mm
6 Needle GROZ-BECKERT 134, 135x17, ORGAN needle DPx5, DPx17
7 Lift of feeding frame Max. 25mm (Pneumatic type only Max.30mm)
8
Intermediate presser stroke
4 mm (Standard) (0 to 10 mm)
9 Lift of intermediate
presser
20 mm
10 Intermediate presser
DOWN position
variable
Standard 0 to 3.5 mm (Max. 0 to 7.0 mm)
11 Shuttle Double-capacity semi-rotary hook
12 Lubricating oil New Defrix Oil No. 2 (Supplied by oiler)
13 Memory of pattern
data
Main body, Media
• Main body : Max. 999 patterns (Max. 50,000 stitches/pattern)
• Media : Max. 999 patterns (Max. 50,000 stitches/pattern)
14 Temporary stop facility Used to stop machine operation during a stitching cycle.
15 Enlarging / Reducing
facility
Allows a pattern to be enlarged or reduced on the X axis and Y axis independently
when sewing a pattern. Scale : 1% to 400% times (0.1% steps)
16 Enlarging / Reducing
method
Pattern enlargement / reduction can be done by increasing / decreasing either stitch
length or the number of stitches. (Increasing/decreasing stitch length only can be
performed when pattern button is selected.)
17
Max. sewing speed
limitation
200 to 2,800 sti/min (Scale : 100 sti/min steps)
18 Pattern selection
facility
Pattern No. selection method
(Main body : 1 to 999, Media : 1 to 999)
19 Bobbin thread counter UP/DOWN method (0 to 9,999)
20 Sewing counter UP/DOWN method (0 to 9,999)
21 Memory back-up In case of a power interruption, the pattern being used will automatically be stored in
memory.
22 2nd origin setting
facility
Using jog keys, a 2nd origin (needle position after a sewing cycle) can be set in the
desired position within the sewing area. The set 2nd origin is also stored in memory.
23 Sewing machine motor Servo-motor
24
Dimensions
1,200mm (W) x 710mm (L) x 1,200mm (H)
(Excluding thread stand)
25 Mass (gross mass) Machine head 69kg, control box 16.5kg
26 Power consumption 450 VA
27
Operating temperature
range
5˚C to 35˚C
28
Operating humidity range
35 % to 85 % (No dew condensation)
29 Line voltage Rated voltage ±10% 50 / 60 Hz
30 Air pressure used Standard 0.35 to 0.4 MPa (Max. 0.55 MPa)(Pneumatic type only)
31 Air consumption 1.8 dm
3
/ min (ANR) (Pneumatic type only)
32 Needle highest
position stop facility
After the completion of sewing, the needle can be brought up to its highest position.
33 Noise - Equivalent continuous emission sound pressure level (L
pA
) at the workstation :
A-weighted value of 82 dB; (Includes L
pA
= 2.5 dB); according to ISO 10821- C.6.3
-ISO 11204 GR2 at 2,800 sti/min
※1
.
- Sound power level (L
WA
) ;
A-weighted value of 91 dB; (Includes K
WA
= 2.5 dB); according to ISO 10821- C.6.3
-ISO 11204 GR2 at 2,800 sti/min
※1
.
Time required for sewing: 2.2 sec, using Pattern No. 102
※1
"sti/min" is an abbreviation for "stitches per minute."
