−35 −
* Changeover procedure of the mode
Each mode can be changed over by simultaneously continuing pressing the buttons below.
™ P mode : +
™ A mode : + [A]
™ C mode : + [C]
™ G mode : + + [C]
™ H mode : + + [D]
P mode
A mode
C mode
G mode
H mode
Max. speed
Slow-start speed
Number of stitches of slow-start
Thread trimming mode
Delay time at the time of S3 signal input before
thread trimming
Needle DOWN stop position angle
Needle UP stop position angle
GAIN high/low changeovera
Alternate motion of IC input signal
Selection of output signal function
Selection of output signal function
Full-wave output time of presser lift output FU
Output mode of L output
Output start angle of L output
Output time of T output
Output start time of W output
Output time of W output
Setting of upper limit value of max. speed H
H
S
SLN
TR
S3D
D8
U8
GA
IF
0C
0D
F0
LLM
LS
T2
W1
W2
LHH
“A or B”
4200 / 4500
250 / 500
2 / 1
J1 / PRG
10 / 60
28 /10
14 / 10
L / H
F / I02
B / L
L / PUL
50 / 25
L1 / L2
0 / 116
90 / 20
10 / 20
8 / 5
90 / 51
“C”
600 / 500
J1 / PRG
28 / 10
50 / 25
0 / 116
90 / 20
10 / 20
8 / 5
End of serial No.
Symbol
DescriptionMode
After executing the setting, perform the change of setting of each mode below.
When returning to the normal mode
: Simultaneously press + .
To Next Page
