– 68 –
(2) Sewing screen
Button and display
COMBINATION DATA NAME display
THREAD CLAMP button
PRESSER DOWN button
RETURN TO ORIGIN button
COMBINATION DATA NO. display
PATTERN BUTTON NO. display
SEWING SHAPE display
Description
Name which is inputted in the combination data being selected is displayed.
Effective/ineffective of thread clamp is selected.
: Thread clamp ineffective
: Thread clamp effective
Presser can be lowered and the presser down screen is displayed.
To raise the presser, press the presser up button displayed in the presser
down screen.
This button returns the presser to the start of sewing and raises the presser
when the present presser position is on the way of sewing.
Combination data No. being selected is displayed.
Pattern button No. being sewn is displayed.
The sewing shape of the currently selected pattern is displayed.
The stitch shape is displayed with color-coded according to the needle
used for sewing.
The section which is
sewn with the right
needle(Orange color)
The section which
is sewn with the left
needle(Light blue)
To Next Page
