JUKI LBH-1702 - Page 111

−111 −
FEED
STEPPING MOTOR CIRCUIT DIAGRAM
BLACK WHITE GREEN RED YELLOW BROWN BLACK WHITE GREEN RED YELLOW BROWN BLACK WHITE GREEN RED YELLOW BROWN
ORANGE WHITE BLUE RED BLACK YELLOW
BLACK YELLOW GREEN RED WHITE BLUE BLACK YELLOW GREEN RED WHITE BLUE
NEEDLE ROCKING
STITCH BASE LINE
