Adjustment Procedures Results of Improper Adjustment
Adjust and fix knife detector sensor installing base 3 and origin
detecting plate 4 with screws 1 and 2 so that the detecting
plate enters upper/lower, right/left and center sections of the
sensor detecting section when the knife bar returns to the upper
side.
Caution : When the knife bar returns to the upper side, turn
pin 5 and make sure that it does not come in
contact with knife detector sensor 6.
