−19 −
Adjustment Procedures Results of Improper Adjustment
Adjust and fix with screws 2 so that starting sensor plate 1
enters in the center of the detecting section of starting sensor 5
when the starting has functioned. The dimension from starting
sensor 5 to the bottom end of starting sensor plate 1 is 1 to 3
mm.
Caution : Make sure that starting sensor plate 1 does not
come in contact with starting sensor 5 when
starting has functioned.
In addition, do not perform the adjustment of the
position of the sensor with starting safety
solenoid base 3 since the play of starting safety
lever 4 is adjusted with starting safety solenoid
base 3.
To Next Page
