Trouble Cause (1) Cause (2) Checking order and adjusting procedure Page
7. Needle breaks.
8. Sewing is occasionally disordered.
9. Tie stitches protrude at 2nd bar-
tacking of radial type shape or round
type shape.
7-1) Other parts come in contact
with needle.
7-2) When operating the needle
thread trimmer, it comes in
contact with needle.
7-3) Needle thread trimmer moves
to the front side and comes in
contact with needle. (B, C
types)
7-4) Basting thread tension is too
high.
8-1) Bobbin thread tension is
improper.
9-1) Position of the start of sewing
is near to the most retreated
position of the feed.
1)-A Blade point of the hook comes
in contact with needle.
1)-B Needle is not in the center of
needle hole in the throat plate.
1)-C Needle is bent.
1)-D Needle thread trimmer comes
in contact with needle.
2)-A Installing position of needle
thread trimmer is improper.
2)-B Needle stop position is too low.
3)-A Engagement of the needle
thread trimmer driving arm and
the driving cam is too tight.
Refer to the item (2) of STANDARD ADJUSTMENT. (Needle-to-hook
timing)
Refer to the items (4) to (6) of STANDARD ADJUSTMENT. (Adjusting
the needle entry point)
Replace the needle.
Refer to the item (25) of STANDARD ADJUSTMENT. (Adjusting the
needle thread trimmer actuating arm)
Refer to the items (19) to (21) of STANDARD ADJUSTMENT. (Installing
position of the needle thread trimmer)
Make sure that main shaft is in the stop position and actuate the needle
thread trimmer. (Lift the presser.)
Refer to the item (25) of STANDARD ADJUSTMENT.
(Adjudting the needle thread trimmer driving arm)
Decrease the basting thread tension, or decrease the pitch.
Re-set the bobbin thread tension to 15g (purl stitching).
Increase the set value of the position of the start of sewing.
(See page 2.)
(See pages 4 to 7.)
(See page 28.)
(See pages 22 to 25.)
(See page 28.)
(See pages 63, 68.)
(See page 68.)
To Next Page
