JUKI LBH-1790S - Specifications

– 2 –
1. Specications
Sewing speed Standard speed : 3,600 sti/min (Max. : 4,200 sti/min) (Max. : 3,300 sti/
min when dry hook is used)
Needle DP×5 #11J to #14J
Hook DP type full-rotary hook
Needle rocking drive method Drive by stepping motor
Feed drive method Drive by stepping motor
Presser lifting drive method Drive by stepping motor
Lift of presser foot 14 mm (Optional setting available) Max. : 17 mm (At the time of nee-
dle up by reverse run)
Cloth cutting knife drive method Motor-driven crank system
Standard sewing shape 31 kinds
Number of patterns stored in
memory
99 patterns
Weight Machine head 55 kg, Control box 5.5 kg
Power consumption 370 VA
Operating temperature range 5 ˚C to 35 ˚C
Operating humidity range 35% to 85% (No dew condensation)
Line voltage AC220 to 240V ± 10% 50/60 Hz
Motor used Single phase AC220 to 240 V, 370 VA
Noise - Equivalent continuous emission sound pressure level (L
pA
) at the
workstation :
A-weighted value of 81.0 dB ; (Includes ; K
pA
= 2.5 dB) ; according
to ISO 10821- C.6.3 -ISO 11204 GR2 at 3,600 sti/min.
