– 6 –
(2) Set-up of the table
1) Fix control box
󱢳
, power switch
󱢵
and pedal sensor
󱢶
on table
󱢴
.
2) Fix power switch
󱢵
with a staple.
3) Pass four bed base xed screws
󱢷
through bed base
󱢸
.
4) Set rubber cushions
󱢹
to holes
󱢺
(4 places) for xing bed base and x bed base
󱢸
.
5) Fix head support bar
󱢻
on table
󱢴
.
6) Place the main unit of the sewing machine on bed base
󱢸
. Then, connect the pedal and pedal sen-
sor
󱢶
with connecting rod
󱢼
supplied with the unit.
󱢴
󱢹
󱢸
󱢺
󱢻
󱢷
󱢼
󱢶
󱢳
󱢵
