– 8 –
4
DRAWING OF TABLE (SEMI-SUBMERGED TYPE) DIRECT-DRIVE TYPE
A
4 - ø 3.4 on the bottom surface, depth 20 (Drill a hole at the time of set-up.)
B
Installing position of drawer stopper (on the reverse side)
C
Drilled hole 17
D
2 - ø 3.4 on the bottom surface, depth 10 (Drill a hole at the time of set-up.)
E
JUKI logotype
F
4 - 10.5 hole, 26 hole facing depth 3.5
R2
20
R2
R2
10
R2
R2
1200
130
810
100
354.5
248 ± 1
23
300
600
500
40
21
50
115
40
570
360
90
60
48
235.5 ± 1
113 ± 1
40
110
23
59
10
390
15
40
75
R30
R30
R30
R6
R30
R6
ø50
A
C
B
R21
E
D
F
163
74.5
97.4
56
(2)
R18
R5
R10
R21
R10
Z
Z
192 ± 1
21
372 ± 1
21
23
46
R21
R5
R5
R21
R21
Z-Z
(4 locations)
(3.5)
(ø26)
(ø10.5)
R21
R10
R10
39
