JUKI MF-7923 User Manual

– 2 –
@
.
CONFIGURATION OF THE MACHINE COMPONENTS
1
Presser spring regulator
!4
Needle tip silicon oil lubricating unit
2
Needle bar thread take-up cover
!5
Differential lock nut
3
Oil circulation inspection windows
!6
Micro-adjustment knob
4
Oil hole cap
!7
Finger guard
5
Micro-lifter
!8
Rocking thread take-up
6
Needle thread silicon oil lubricating unit
!9
Front cover
7
Thread guide No. 1
@0
Needle bar thread take-up thread receiver
8
Upper pulley
@1
Silicon container thread guide
9
Thread tension nut
@2
Belt cover
!0
Oil gauge
@3
Differential feed regulating lever
!1
Feed regulating knob
!2
Eye guard cover
!3
Throat plate
1
2
3
4
6
8
9
!1
!3
!5
!6
!7
!8
@2
!9
@0
@3
@1
5
!2
7
!4
!0
