– 23 –
14. Adjusting the presser foot liftAdjusting the presser foot lift
To adjust the height of the presser foot, adjust the
height of screw
1
so that the presser foot does not
come in contact with other components and x the
presser foot with nut
2
.
15. Adjusting the micro-lifter
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the fol-
lowing work after turning the power off and ascertaining that the motor is at rest.
WARNING :
To protect against possible personal injury due to abrupt start of the machine, be sure to start the fol-
lowing work after turning the power off and ascertaining that the motor is at rest.
1
2
When the micro-lifter collar
1
is turned clockwise
and counterclockwise, the presser bar lifting lever is
pressed down to lift the presser foot.
Adjust the height of the micro-lifter according to the
sewing condition.
In the case the micro-lifter is not used, use
the sewing machine with the marker line on
the micro-lifter collar faced straight up.
1
