Operation and function
Handwheel (Pulley)
The handwheel turns toward you.
* Upon completion of threading, at sewing start or sewing end, be
sure to turn the handwheel toward you.
Opening and closing the looper cover
Opening: To open the looper cover, pull the looper cover opening
handle to the right, and tilt the looper cover toward you.
Closing: To close the looper cover, push up the looper cover, press
it lightly to the right. The looper cover closes automatical-
ly.
Opening and closing the cloth plate
Opening: Press the cloth plate toward the outside.
Closing: Push the cloth plate toward the sewing machine.
CAUTION :
[ MO-654DEN ]
For safety, the power is automatically cut off when you
open the looper cover or the cloth plate.
CAUTION :
[ MO-654DEN ]
For safety, the power is automatically cut off when you
open the looper cover or the cloth plate.
Switch the machine off (power switch ”O”)
Switch the machine off (power switch ”O”)
10
