JUKI SC-510 Engineer's Manual

−56 −
Simplified program sheet
Step
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
End,DELy,And,or,
STiA,Stio,JUMP,
SPEd,,LiMi,LinH,
TrM,TinH,UP,HS,
rSW,AnGA,AnGo,
SToP,bT,FL,rEST
Co. command
1:opo0,2:opo1,3:opo2,
4:opo3,5:opo4,6:opo5,
7:opo6,8:opo7,9:BZ
oH. oL. output information
1:opi0,2:opi1,3:opi2,4:opi3,5:opi4,6:opi5,7:opi6,
8:opi7,9:opo0,10:opo1,11:opo2,12:opo3,13:opo4,
14:opo5,15:opo6,16:opo7,17:TRMD,18:WPD,
19:TLSUBD,20:BTD,21:FLD,22:BZ,23:M_ERR,
24:S.STATE,25:HstSW:CP-Panel,26:LSSW,
27:BTSW,28:UDET,29:DDET,30:UP,31:DOWN,
32:SET+,33:SET–
iH. iL. input information
Pn. Program No.
Sn. Step No.
S. Speed
nf.on/off
Parameter 1
d. Delay time
r. Repeat counter
C. Number of stitches
A. Angle
Parameter 2
Number of stitches : 1 stitch unit
Time : 1 ms unit
Speed : 10 rpm unit
Angle : 1 degree unit
Remarks
