− 2 −
3. CONFIGURATION
(1) SC-510/M51
2
1
6
3
4
5
1 : M51 (AC servo motor)
2 : Front cover
3 : Operation panel
4 : Pedal unit
5 : Power connector
6 : Motor connector
