1. SPECIFICATIONS
(1) Features
1) Voltage changeover function of single phase 100 to 120V/3-phase 200 to 240V is provided. (Adapting to a
part of specifications only)
The control box with voltage changeover function can be used either for single phase 100 to 120V or for 3-
phase 200 to 240V by replacing the power cord up to the power switch and setting the voltage changeover
connector inside the control box.
2) By connecting the operation panel, CP-160 to the control box as standard, function and operability are
further improved.
3) SC-510 main unit only has the programming function and it is possible for SC-510 main unit only to program
various input/output such as start, stop, etc. of the sewing machine by means of the external equipments or
external input/output signals by using the optional input/output terminals.
4) Version-up of the program of SC-510 main unit and extension of input/output terminals can be performed by
using the optional IP-100 and the extension p.c.b.
5) Reliability is further improved by employment of the switching power method which is strong against the
voltage fluctuation and strengthening of the protective circuit.
6) High-torque servo motor M51 of 750 W output is employed and a wide range adaptability from general
materials to extra heavy-weight materials can be displayed.
2. OUTLINE
(2) Extension p.c.b. * (packed together with IP-100E)
No. Item Specifications
1 Panel connection port IP-100E connection port
2 Number of input ports 8
3Number of output ports 8
4 Memory medium Smart media
5 Program input IP-100E
(1) SC-510/M51
(Caution) 1. Indication of the power consumption is the mean power consumption when LU-1520N-
7 is mounted in accordance with the operating conditions JUKI specifies.The power
consumption changes in accordance with the operating conditions and the mounted
machine head. So, be careful.
2. Instantaneous maximum power consumption may become 1.5 times or more than the
mean power consumption.
No. Item Specifications
1 Supply voltage
Single phase 100 to 120V 3-phase 200 to 240V Single phase 200 to 240V
2 Frequency 50 Hz / 60 Hz 50 Hz / 60 Hz 50 Hz / 60 Hz
3
Operating temperature range Temperature : 0 to 40˚C Temperature : 0 to 40˚C Temperature : 0 to 40˚C
4
Operating humidity range Humidity : 90% or less Humidity : 90% or less Humidity : 90% or less
5Power consumption 425VA 425VA 425VA
6 Number of input ports 8 8 8
7 Number of output ports 8 8 8
8 Number of programs 4 4 4
9 Number of steps 20 steps/1 program 20 steps/1 program 20 steps/1 program
10
Program input Control box or Control box or Control box or
operation panel (optional) operation panel (optional) operation panel (optional) operation panel (optional)
11 Operation panel CP-160C CP-160C CP-160C
(optional) IP-100E IP-100E IP-100E
