– 11 –
Information screen (Maintenance personnel level)
: Ver display
: Function setting
: Sewing management
information
: Communication mode
: Smart media format
[Maintenance personnel level]
1) Turn ON the power. When the needle bar is not in the UP position, turn the handwheel to bring the needle bar
to its UP position.
2) Press switch for approximately three seconds to display the information screen.
3) Press switches , , , and corresponding to the various functions.
2. Ver display
Software version of each CPU is displayed.
Press switch in the information screen (maintenance personnel level).
Ver display screen
Explanation of display
Others
Level
Version
Revision
Kind of CPU
01- 01 01 00
RVL
Panel software
Servo motor software
To Next Page
