– 33 –
No. Item Description Setting range
116 Selection of When the IP-100 is connected, switch selection is performed to start in-corner 0 to 6 46
corner teaching sewing in the case of corner pattern sewing.
start switch 0: No function
1: Left needle selector switch
2: Right needle selector switch
3: Teaching switch
4: Optional switch
5: Knee switch, presser lifter switch
6: No function (Don’t care.)
* When 1: left needle selector switch, 2: right needle selector switch, or
3: teaching switch is selected for the in-corner selector switch, set No.111
unilateral needle selection function (corner pattern) at 0 (function disabled),
without fail.
* Setting is possible only if LH-4168 or LH-4188 is selected for the machine head.
117 Selection of When the knee switch is connected, selection is performed to stop/start the 0/1 47
presser lifter automatic presser lifter function by means of the knee switch.
switch function 0: OFF The automatic presser lifter is stopped with the knee switch.
1: ON The automatic presser lifter is used with the knee switch.
* Setting is possible only if LH-4168 or LH-4188 is selected for the machine head.
* When using this function, it is necessary to set up the presser lifter switch 1
(No.106) at 0 (function disabled).
118 Grease up error In the case of grease-up error (E220, E221), this error is cleared by setting 0/1 47
reset the setup description at 1.
0: Normal condition
1: Grease-up error reset when the power is turned on for the next time
(After grease-up error has been reset, this function is also canceled.)
* Prior to resetting the grease-up error, grease-up treatment is always needed.
* Setting is possible only for the machine head (part of the LH-4100 or
LH-3500 Series) where grease-up treatments are needed.
116
5
117
0
118
0
Indication of Ref.
function setting page
To Next Page
