Julabo FT402 - Technical Specifications

Immersion Coolers
15
2.4. Technical specifications
Immersion cooler FT402
Working temperature range °C -40 ... 30
Temperature stability °C ±0.5
Temperature selection digital
Temperature indication LED
Resolution °C 0.1
Temperature control PID1
Cooling capacity
Medium ethanol
°C
kW
+20 10 -20 -40
0.45 0.36 0.14 0.03
Cooling compressor 1-stage
Refrigerant 230 V / 50 Hz
115 V / 60 Hz
R452A
R404a
Electrical connections:
Pt100 external sensor Pt100
Overall dimensions (WxDxH) cm 20x30x43
Immersion probe (Lxdia.) cm 12x5
Immersion probe, flexible (Lxdia.) cm -------
Connection tubing (L) cm 120
Noise level, distance 1 m dBA 61
Weight kg 24
Ambient temperature °C 5 ... 35 (32 with R452A)
Mains power connection V/Hz 230/50/60
Current input (at 230 V) A 3
Mains power connection V/Hz 115/60
Current input (at 115 V) A 4
All measurements have been carried out at: rated voltage and frequency. Ambient
temperature 20 °C.
