3 Mounting
3.6 Mounting the probe
For thermostats with long-
distance line (abbreviation
"f"), the temperature probe
is fastened in the sheath by
means of the clamping
piece (1) for connection
types "20".
H
Submerge the sheath and the temperature probe (2) into the medium and
ensure that the temperature probe (2) is completely submerged in the medium
because otherwise, greater switching point deviations will occur.
( 1 )
( 2 )
