3 Mounting
3.1 Dimensions
ATHs-SE-2,
ATHs-SE-20
with
sheath "20"
(up to +150 °C)
K M24x1,5
M 20x1,5
DIN 89280-Z14
27
70
66
G1/2
33
14
Ø 26
S = max. 200 (150)
67
94
