JUMO diraTRON 132 Interface Description

33
4 Modbus addresses
4.2.3 Process values
Analog process values
In this section, different analog process values are listed under consecutive addresses so that they can
be extracted using a read operation.
Some of these process values are also listed in the section of the respective function – under a different
address.
Address Data type Access Designation Type
a
Hex. Dec. 70211x 70151x
0x7000 28672 FLOAT R/O Analog input (measured value) X X
0x7002 28674 FLOAT R/O Min. value --- X
0x7004 28676 FLOAT R/O Max. value --- X
0x7006 28678 FLOAT R/O Tara value --- X
0x7008 28680 FLOAT R/O 1. math result X X
0x700A 28682 FLOAT R/O 2. math result X X
0x700C 28684 FLOAT R/O 3. math result X X
0x700E 28686 FLOAT R/O 4. math result X X
0x7010 28688 FLOAT R/O Controller setpoint value X ---
0x7012 28690 FLOAT R/O Controller actual value X ---
0x7014 28692 FLOAT R/O Control deviation X ---
0x7016 28694 FLOAT R/O Output level display X ---
0x7018 28696 FLOAT R/O 1. setpoint value X ---
0x701A 28698 FLOAT R/O 2. setpoint value X ---
0x701C 28700 FLOAT R/O 3. setpoint value X ---
0x701E 28702 FLOAT R/O 4. setpoint value X ---
0x7020 28704 FLOAT R/O Ramp end value X ---
0x7022 28706 FLOAT R/O Current ramp setpoint value X ---
0x7024 28708 FLOAT R/O 1. ext. analog input X X
0x7026 28710 FLOAT R/O 2. ext. analog input X X
0x7028 28712 FLOAT R/O 1. analog flag X X
0x702A 28714 FLOAT R/O 2. analog flag X X
0x702C 28716 FLOAT R/O Timer run time X X
0x702E 28718 FLOAT R/O Timer remaining running time X X
0x7030 28720 FLOAT R/O Timer value X X
0x7032 28722 FLOAT R/O Current section X ---
0x7034 28724 FLOAT R/O Section end value X ---
0x7036 28726 FLOAT R/O (reserved) --- ---
0x7038 28728 FLOAT R/O Remaining section time X ---
0x703A 28730 FLOAT R/O Remaining program time X ---
0x703C 28732 FLOAT R/O Section run time X ---
0x703E 28734 FLOAT R/O Program run time X ---
0x7040 28736 FLOAT R/O Current program setpoint value X ---
0x7042 28738 FLOAT R/O (reserved) --- ---
0x7044 28740 FLOAT R/O 1. ST analog output X X
0x7046 28742 FLOAT R/O 2. ST analog output X X
0x7048 28744 FLOAT R/O 3. ST analog output X X
0x704A 28746 FLOAT R/O 4. ST analog output X X
