JUMO EM Series Operating Instructions

6 Device Description
22
Protection class EN 60 529 - IP 00
Degree of soiling 2
Operating
medium
Water, oil, air, hot steam
Time constant
t
0.632
Function as per EN 60 730-1 and DIN EN 60 730-2-9 and DIN EN 14597
STW(STB): 2 BKLNP
STB 2 BFHKLNPV
Rated position any
Weight approx. 0.2 kg
Material
of capillary and
probe
minimum
bending radius
of the capillar-
ies
5mm
in water in oil in air / hot steam
≤ 45 s ≤ 60 s ≤ 120 s
Scale limit value Capillary Sensors
up to +200 °C Copper mat.No.: Cu-DHP
Ø 1.5 mm
Copper, mat.No.: Cu-DHP
hard soldered
up to +350 °C Copper mat.No.: Cu-DHP
Ø 1.5 mm
Stainless steel, mat.No.:
1.4571
hard soldered
up to +500 °C Stainless steel,
Ø 1.5 mm
Stainless steel, mat.No.:
1.4571
welded
against surcharge
up to +350 °C Stainless steel,
Ø 1.5 mm
Stainless steel, mat.No.:
1.4571
welded
