JUMO EM Series Operating Instructions

23
6 Device Description
Average
ambient tem-
perature
influence
(in % from the scale range) referring to the limit value.
When the ambient temperature on the switch head and / or the capillary devi-
ates from the calibration ambient temperature +22 °C, a switching point offset
occurs.
Higher ambient temperature = lower switching point
Lower ambient temperature = higher switching point
Temperature
compensation
"707"
For detailed information, please refer to the graphical presentation in data
sheet 602026
For temperatures with scale limit value / limit value:
< +200 °C ≥ +200 °C ≤ +350 °C ≥ +400 °C ≤ +500 °C
STW (STB)
Hysteresis in %
77 10
Ambient temperature influence on the switch head in %/K
0.43 0.35 0.24
Ambient temperature influence on the capillary in %/m
0.09 · K · m 0.07 · K · m 0.05 · K · m
STB
Ambient temperature influence on the switch head:
0.35 K/K
Ambient temperature influence on the capillary in K/m
0.07 K/K·m
