167
11.14 EN
4.6 Tilting the Cab
DANGER!
X
Before tilting the cab, allow the motor
and muffler to cool off. Unlock the
muffler and tilt it back.
Procedure
• To do this release the lever (236) and
unlock the button (235). The muffler
can be carefully turned back as far as
the stop.
• After the cab is lowered, move the muffler back to its vertical position and lock it in
place.
4.6.1 Raising the Cab Manually
Procedure
• Remove the pump rod (239) from the
holder behind the driver's seat.
• The lift pump is fed into the cab through
inlets in the chassis on the right side of the
truck (237 = lift; 238 = lower)
CAUTION!
Before activating the lift pump always
close the lowering valve.
•
• To close, insert the long side of the pump
rod through the infeed (238) onto the hex.
bolt of the lowering valve and carefully
turn clockwise.
