175
11.14 EN
4.9.1 Checking the hydraulic oil level
Requirements
– Park the truck on a level surface.
– Start the engine and fully raise and lower
the mast once.
– Switch off the engine.
Procedure
• Remove the hydraulic oil dipstick (242)
from the hole, wipe it with a clean cloth and
insert it fully again.
• Remove the hydraulic oil dipstick and
check the level of the hydraulic oil.
Z For cold oil: the oil level should lie between
the MIN and MAX markings.
For hot oil: the oil should lie just above the
MAX marking.
• The difference between MIN and MAX is
approximately 10 litres.
• Add hydraulic oil if necessary.
• Repeat the test.
• When the oil level is correct, fully insert the hydraulic oil dipstick (242) again.
