8.2 Sliding windows
CAUTION!
An unlocked sliding window can cause accidents
XThe sliding windows must be locked at all times.
Opening and closing the windows
Procedure
• Push the lock (197) up.
• Move the window forward or back.
• Insert the lock in the stop (198).
8.3 Emergency Exit
If a locking pin in the closing mechanism is removed, the right side window can be
used as an emergency exit.
Procedure
• Open the window to its normal open position
• Use the upper ring to pull the locking pin out of the closing mechanism.
• Open the window all the way.
8.4 Driver'S Seat Heater
