Jungheinrich EFG 535 User Manual

0708.GB
B 4
3 Standard Version Specifications
3.1 Performance data
Description EFG
535
EFG
540
EFG
545
EFG
550
h
1
Mast height retracted 2405 2405 2405 mm
h
2
Free lift 150 150 150 150 mm
h
3
Lift 3000 3000 3000 mm
h
4
High mast extended 3830 3830 3830 mm
h
6
Height above overhead guard
(cabin)
2320 2320 2320 2320 mm
h
7
Seat height / standing height 1165 1165 1165 1165 mm
Seat freedom H1 1105 1105 1105 1105 mm
h
10
Coupling height 390/
500
390/
500
390/
500
390/
500
mm
L
1
Overall length, including Forks 3975 3980 3980 3980 mm
L
2
Length including forks back 2830 2830 2830 2830 mm
b1 Overall width 1340 1340 1340 1450 mm
b3 Fork carriage width 1120 1260 1260 1260 mm
m
1
Ground clearance with load below
mast
120 120 120 120 mm
m
2
Ground clearance centre wheelbase 160 160 160 160 mm
Ast Working aisle width @
800 x 1200 length
4260 4260 4260 mm
Ast Working aisle width @
1000 x 1200 traverse
4060 4060 4060 mm
W
a
Turning radius 2450 2450 2450 mm
x Load distance (DZ mast + 32 mm) 510 510 510 mm
y Wheelbase 1855 2000 2000 2000 mm
Description EFG 535 EFG 540 EFG 545 EFG 550
Q Capacity/Load 3.5 4.0 4.5 4.99 t
c Load centre of gravity 500 500 500 500 mm
Travel speed w / w.o.
load
16/17 15/17 15/16.5 15/16 km/h
Lift speed w / w.o. load 0.38/0.50 0.35/0.47 0.33/0.45 0.31/0.45 m/s
Lowering speed
w / w.o. load
0.58/0.55 0.55/0.50 0.55/0.50 0.55/0.50 m/s
Gradeability
w / w.o. load S2
30 min
8.5/14.5 8/13.5 7/12 6.5/12 %
Max. gradeability
w / w.o. load S2
5 min
15.5/25 14/23.5 12.5/21.5 12/21 %
0708.GB
B 4
3 Standard Version Specifications
3.1 Performance data
Description EFG
535
EFG
540
EFG
545
EFG
550
h
1
Mast height retracted 2405 2405 2405 mm
h
2
Free lift 150 150 150 150 mm
h
3
Lift 3000 3000 3000 mm
h
4
High mast extended 3830 3830 3830 mm
h
6
Height above overhead guard
(cabin)
2320 2320 2320 2320 mm
h
7
Seat height / standing height 1165 1165 1165 1165 mm
Seat freedom H1 1105 1105 1105 1105 mm
h
10
Coupling height 390/
500
390/
500
390/
500
390/
500
mm
L
1
Overall length, including Forks 3975 3980 3980 3980 mm
L
2
Length including forks back 2830 2830 2830 2830 mm
b1 Overall width 1340 1340 1340 1450 mm
b3 Fork carriage width 1120 1260 1260 1260 mm
m
1
Ground clearance with load below
mast
120 120 120 120 mm
m
2
Ground clearance centre wheelbase 160 160 160 160 mm
Ast Working aisle width @
800 x 1200 length
4260 4260 4260 mm
Ast Working aisle width @
1000 x 1200 traverse
4060 4060 4060 mm
W
a
Turning radius 2450 2450 2450 mm
x Load distance (DZ mast + 32 mm) 510 510 510 mm
y Wheelbase 1855 2000 2000 2000 mm
Description EFG 535 EFG 540 EFG 545 EFG 550
Q Capacity/Load 3.5 4.0 4.5 4.99 t
c Load centre of gravity 500 500 500 500 mm
Travel speed w / w.o.
load
16/17 15/17 15/16.5 15/16 km/h
Lift speed w / w.o. load 0.38/0.50 0.35/0.47 0.33/0.45 0.31/0.45 m/s
Lowering speed
w / w.o. load
0.58/0.55 0.55/0.50 0.55/0.50 0.55/0.50 m/s
Gradeability
w / w.o. load S2
30 min
8.5/14.5 8/13.5 7/12 6.5/12 %
Max. gradeability
w / w.o. load S2
5 min
15.5/25 14/23.5 12.5/21.5 12/21 %
