Jungheinrich ERC 214 User Manual

Reference ERC 212 /
212z
ERC 214 /
214z
ERC 216 /
216z
Standard 290 ZT mast 280 ZT
l
1
Overall length* 2046 / 2060 2067 / 2081 2067 / 2081 mm
l
2
Headlength* 896 / 910 917 / 931 917 / 931 mm
h
1
Mast height (retracted), for
100 mm lift
1950 1950 1950 mm
(h
2
) Free lift 100 100 100 mm
h
3
Lift 2900 2900 2800 mm
h
4
Mast height (extended) 3375 3375 3325 mm
h
13
Lowered fork height 90 90 90 mm
h
14
Tiller height in travel
position (min.)
1158 1158 1158 mm
Tiller height in travel
position (max.)
1414 1414 1414 mm
y Wheelbase 1336 / 1571 1357 / 1592 1357 / 1592 mm
x Load distance* 688 / 910 688 / 910 688 / 910 mm
b
1
/b
2
Overall width 800 800 800 mm
b
5
Width across forks 570 570
570
mm
b
10
Track width, front 507 507
507
mm
b
11
Track width, rear 400 / 385 400 / 385
400 / 385
mm
s Fork dimensions 56 56 56 mm
e Fork dimensions 185 185 185 mm
l Fork dimensions 1150 1150 1150 mm
m
2
Ground clearance, centre
of wheelbase
30 / 20 30 / 20 30 / 20 mm
Wa Turning radius 1597 / 1826 1618 / 1847 1618 / 1847 mm
Ast Aisle width for pallets 1000
x 1200 crossways
*)**)
2259 / 2266 2280 / 2287 2280 / 2287 mm
Ast Aisle width for pallets 800 x
1200 lengthways
*)***)
2309 / 2316 2330 / 2337 2330 / 2337 mm
Net weight: see "Weights" in chapter 4.3
*)
DZ: x -42 mm, l
1
+42 mm, l
2
+42 mm
**)
Diagonal in accordance with VDI: +215 mm
***)
Diagonal in accordance with VDI: +138 mm
25
04.19 en-GB
