Jungheinrich ERC 214 - Changing the Battery from the Top

5.1 Changing the battery from the top
Z
ERC 212/214/216
Removing the battery
Requirements
– Park the truck securely, see page 76.
– Expose the battery, see page 46.
Tools and Material Required
– Crane lifting gear
Procedure
• Disconnect the battery connector from the truck connector.
Z
Place the battery cable on the tray so that it cannot be severed when the battery
is pulled out.
• Attach the crane lifting gear to the eyes (51).
Z
The hooks must be fitted in such a way that when the crane lifting gear is
slackened, they do not fall onto the battery cells. The lifting gear must exert a
vertical pull so that the battery container is not compressed.
• Lift the battery slowly out of the battery compartment using crane lifting gear.
The battery has now been removed.
51
57
04.19 en-GB
