Figure 34: Connecting the PP833 Processor with the PC DB-9M Serial Console
6—1— RJ-45 male endPP833 front panel
7—2— Straight RJ-45 cableCable 720-071594
8—3— RJ-45 male endDB-9 male end of 720-071594
9—4— Adapter from the bag labelled 720-014126DB-9 female end of adapter from the bag labelled
720-056657
10—5— DB-9 male end of PCAdapter from the bag labelled 720-056657
RELATED DOCUMENTATION
CTP2000 Console Port Setup | 122
CTP Fast Ethernet and Power Cables | 68
CTP Fast Ethernet and Power Cables
IN THIS SECTION
Fast Ethernet Cables | 69
DC Power Cables | 69
