Juniper Day One+ MX304 User Manual

Meet the MX304 Universal Router
The MX304 router provides a highly compact, 2 U plaorm with the exibility to scale out services with 4.8 Tbps
system capacity. Based on Juniper Networks Trio 6 chipset, the MX304 router is designed and opmized for a wide
range of demanding edge requirements (business, residenal, mobile, cable, data center and more) anywhere in the
network.
The MX304 router runs the Junos operang system (Junos OS). It has pluggable Roung Engines (it supports one or two
Roung Engines), two dedicated AC, DC, or HVAC/HVDC power supply modules, and front-to-back cooling. It accepts
up to three line card MICs (LMICs), each with a Trio 6.0 chipset and 1.6 Tbps of forwarding capacity. The MX304 router
supports a maximum of 12x400 Gbps ports, 48x100 Gbps ports or a combinaon (with three LMICs).
Install the MX304
IN THIS SECTION
What's in the Box? | 2
What Else Do I Need? | 3
Install the MX304 Router in a Four-Post Rack | 3
What's in the Box?
• MX304 router preinstalled with Roung Engines, LMICs, fan trays, power supplies, and cover panels for the empty
line card slots.
• Rack mounng brackets (preinstalled on the chassis)
• AC power cables appropriate for your geographic locaon
• Cable management bracket with cable manager screws
• Ethernet cable, RJ-45 to DB-9 adapter
2

Juniper Day One+ MX304 Specifications

General

Model	MX304
Category	Network Router
Operating System	Junos OS
Power Supply	Dual redundant AC or DC power supplies
Operating Temperature	0° to 40° C (32° to 104° F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 90% non-condensing
