Table 4: Specifications for the LTE Mini-PIM Antenna (continued)
ValueSpecification
•
704~960 MHz
•
1710~2700 MHz
Operating frequency range
5 (maximum)Voltage Standing Wave Ratio (VSWR)
50 ohmImpedance
OmnidirectionalRadiation
•
2.45 dBi (704~960 MHz)
•
4.51 dBi (1710~2700 MHz)
Peak gain
1 WInput power
Linear, verticalPolarization
–4° F (–20° C) to 149° F (65° C)Operating temperature
SMAConnector type
203 mmLength
The antenna is connected to the services gateway through the magnetic antenna base. Table 5 on page 4
lists the specifications for the antenna base.
Table 5: Antenna Base Specifications
ValueSpecification
BS-05SF-174-3M-0102 (Vendor: Chang Hong)Part number
3 mCable length
SMAConnector type
29.50 mm x 73 mm x 73 mmDimensions (H x W x L)
Table 6 on page 5 provides a summary of the different models of the Mini-PIM.
