Juniper M7i Installation Instructions

AC Grounding and P
ower Cord Specifications
Power Supply LED
Ta b l e 3 d e s c r i
bes the LED on both AC and DC power supplies.
Table 3: States for Power Supply LED
Label Color State Description
On steadily Power supply is functioning normally, input is
occurring, outputs are within range, and the
temperature is within range.
OUTPUT
OK
Green
Blinking Power supply is starting up, is not properly
inserted, or
airflow is not sufficient.
AC Grounding and Power Cord Specifications
To ground an
AC-powered router, plug each power supply into a grounded AC power
receptacle. The receptacle provides the grounding for the router, so no additional grounding
is necessary. The receptacle must be within about 8 ft (2.5 m) of the router and must be
easily acce
ssible.
Detachable AC power cords, each 2.5 m (approximately 8 ft) long, are supplied with the
router. Th
eappliancecoupleratthefemaleendofthecordinsertsintotheapplianceinleton
the faceplate of the AC power supply. The coupler is type C13 as described by International
Electrotechnical Commission (IEC) standard 60320. The plug at the male end of the power
cord fits i
nto the power source receptacle that is standard for your geographical location.
In North America, AC power cords must not exceed 4.5 m (approximately
14.75 ft) in length, to comply with National Electrical Code (NEC) Sections
400-8 (NFPA 75, 5-2.2) and 210-52, and Canadian Electrical Code (CEC)
Section 4-010(3). The cords supplied with the router are in compliance.
Table 4 provides specifications and Figure 3 depicts the plug on the AC power cord provided
for each
country or region.
Table 4: AC Power Cord Specifications
Country Electrical Specification Plug Type
Australia
240 VAC, 50 Hz AC
SAA/3
Europe (except Italy and United Kingdom)
220 or 230 VAC, 50 Hz AC
VII
Italy
230 VAC, 50 Hz AC
I/3/16
4 M7iandM10iInternetRoutersPowerSupplyInstallationInstructions
