See Also MX5, MX10, MX40, and MX80 Routing Engine Description on page 42•

• Maintaining the MX5, MX10, MX40, and MX80 Routing Engine on page 97

RJ-45 Connector Pinouts for the ETHERNET Port on MX5, MX10, MX40, and MX80 Routers

The port on the front panel labeled ETHERNET is an autosensing 10/100-Mbps Ethernet

RJ-45 receptacle that accepts an Ethernet cable for connecting the Routing Engine to a

management LAN (or other device that supports out-of-band management).

Table 40 on page 73 describes the RJ-45 connector pinout.

Table 40: RJ-45 Connector Pinout for the Routing Engine ETHERNET Port

SignalPin

TX+1

TX–2

RX+3

Termination network4

Termination network5

RX–6

Termination network7

Termination network8

Chapter 2: Site Planning, Preparation, and Specifications
