JA94-N01A Dual Audio Controller - NVG
Installation and Operating Manual
Rev A Page 10
2.5.3.4 Transmit Levels
When the Transmit Timeout check box is checked the transmit time-
out is enabled (Default not checked)
When the COM5 Duplex check box is checked the COM5 (FM2) radio
is set to duplex operation (Default not checked) (see section 3.3.4)
2.5.3.5 Simulcast Selection
The level of each of the six Transceiver MIC output signals can be
ad
usted from 0.01 to 1 Vrms.
Default 250 mVrms
When a User's COM6 Simulcast Enable button is
checked, the COM1 through COM5 radios may be
selected for simulcast (active together).
