Jupiter Avionics JA94-N01A - Page 34

JUPITER AVIONICS TEMPLATE AUTOCAD PORTRAIT SIZEA REV B.DWT
TITLE
APPROVED
PREPARED
CHECKED
L00N3
NCAGE CODE PART NO. SHEET
DOC NO.
Dual Audio Controller - NVG
Interconnect Options
JA94-N01A 5/6
JA94-N01A Interconnect Rev A.dwg
TAT
LEFT RX COMP OUT HI
LEFT RX COMP OUT LO
HI
LO
RECORDER
14
33
JA94-N01A
P/O J1
P/O P1
37 PIN FEMALE DMIN
MATING CONNECTOR
OPTION: LEFT RX COMPOSITE OUT
OPTION: RIGHT RX COMPOSITE OUT
CHASSIS GROUND
JA94-N01A
J5 THREADED STUD 4-40 0.25 in.
OPTION: CHASSIS GROUND
22 AWG
RIGHT CVR HI
RIGHT CVR LO
HI
LO
13
32
JA94-N01A
P/O J1
P/O P1
37 PIN FEMALE DMIN
MATING CONNECTOR
OPTION: RIGHT CVR
LEFT CVR HI
LEFT CVR LO
HI
LO
1
20
JA94-N01A
P/O J1
P/O P1
37 PIN FEMALE DMIN
MATING CONNECTOR
OPTION: LEFT CVR
RIGHT CVR
LEFT CVR
RIGHT RX COMP OUT HI
RIGHT RX COMP OUT LO
HI
LO
RECORDER
15
34
JA94-N01A
P/O J1
P/O P1
37 PIN FEMALE DMIN
MATING CONNECTOR
PAX 6 MIC HI
PAX 6 MIC LO
MIC
LO
PAX 6
23
40
PAX 6 TX PTT
6
OPTION: PAX 6 HEADSET
JA94-N01A
P/O J2
P/O P2
50 PIN FEMALE DMIN
MATING CONNECTOR
PAX 5 & 6 PHN HI
PHN16
PAX 4, 5 & 6 PHN LO
LO
50
HEADSET JACK
PAX 6 TX PTT
