jurop LC User Manual

SPARE PART DATA SHEET – LC 300-420-580 M
REV. 12
10-12-2021
29 / 44
Jurop SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
TEL. +39 0434 636811 FAX. +39 0434 636812
http://www.jurop.it
e-mail: info@jurop.it
103
4026501003
TAB 12X8X40
1
111
4026904503
PLUG M20X1,5
1
104
4026701603
PLUG ½ ZINC.
1
112
4026905002
PLUG ¼ ZINC.
2
105
4026702000
FITTING 4X1/8
4
113
4026910103
VENTIL PLUG 1
1
106
4026706000
FITTING 90° 4X1/8
4
114
4026910601
PLUG 1/8”
2
107
4026706003
FITTING 90° 6X1/8
2
115
4029602701
NUT M8 PROTECTION
1
108
4026706101
ADJUSTABLE FITTING 4X1/8
2
116
4029602806
DRIVE SHAFT PROTECTION
1
109
4026904003
PLUG 1" ZINC.
6
110
4026904300
VENTIL VALVE 1/4
2
189207X0B0
GASKET KIT LC 420 WITH GEARBOX
LC 580 WITH GEARBOX (540-1000 RPM)
Pos.
Code
Description
Q.ty
Pos.
Code
Description
Q.ty
1
1401200700
OIL DRIPPER
2
45
1684000000
DISCHARGE PLUG 3/8
3
2
1407200800
WATER PUMP (LC M RIGHT)
1
46
1685002800
WASHER 30X8,5 SP.4 ZINC.
1
1407200900
WATER PUMP (LC M LEFT)
1
47
1685100000
OIL DRIPPER WASHER 14X20X1,5
2
3
1521507400
ROTOR LC 580
1
48
1685100100
WASHER 10X16X1,5
2
4
154201TUB0
BELT PROTECTION LC M RIGHT
1
49
1685100200
WASHER 17X22X1,5
3
154201TSB0
BELT PROTECTION LC M LEFT
1
50
1685100300
WASHER DI 20
2
5
16016BXNB0
VANE LC 580
5
51
1687511000
LC 580 PUMP HOUSING
1
6
1605500100
HANDLE
1
52
1687600000
OIL TANK
1
7
1608100000
DISTRIBUTOR
1
53
1691000000
SPRING
1
8
1608502500
CONVEYOR
1
54
18930008E0
CLAPET D.110 WITH OR
1
9
1610051700
FLANGE
1
55
4022200008
Y-SEAL 90X45X8
1
10
1610512900
OIL PUMP FLANGE
1
56
4022200030
Y-SEAL 41X27X10
1
11
1610514300
FLANGE
1
57
4022200040
Y-SEAL 72X40X10
1
12
1610514400
GEARBOX FLANGE
1
58
4022200113
Y-SEAL 70X55X15 (ONE ON EACH SIDE)
2
13
161201X4B0
PUMP SUPPORT
1
59
4022300001
OIL FILTER D.6
1
14
1613501400
OIL PUMP SUPPORT
1
60
4023100020
BEARING 6207
1
15
1622002600
SHAFT M10
1
61
4023100039
BEARING 6308/C3
1
15A
4026414617
PIN 3X40 (LC M RIGHT ROTATION)
1
62
4023100047
BEARING 6309/C3
2
16
1623100500
CONVEYOR FLANGE
1
63
4024251000
OIL PUMP CW ROTATION (LC M L)
1
17
1624037500
SPACER
1
4024251500
OIL PUMP CCW ROTATION (LC M R)
1
18
162403N3B0
SPACER
1
64
4025350020
CINGHIA SPZ 950
1
19
1624042800
SPACER
2
65
4025426003
BUSHING D.40
1
20
162409YKB0
SPACER
1
66
4025426209
PULLEY SPZ 150X1
1
21
1624202300
4 WAYS SPACER
1
67
4026101301
SCREW TE 8.8 M6X10 ZINC.
2
22
16275007E0
MANIFOLD
1
68
4026102804
SCREW TE 8.8 M8X16 ZINC.
3
23
16401008E0
CLAPET COVER
1
69
4026102806
SCREW TE 8.8 M8X20 ZINC.
4
24
164059V5B0
FRONT PROTECTION
1
70
4026102807
SCREW TE 8.8 M8X25 ZINC.
19
25
1642100200
REAR PROTECTION
1
71
4026102810
SCREW TE 8.8 M8X40 ZINC.
8
26
1651005300
PINION Z25 (MOLT. 540 RPM)
1
72
4026102819
SCREW TE 8.8 M8X90 ZINC.
1
165109KFB0
PINION Z37 (MOLT. 1000 RPM)
1
73
4026102904
SCREW TE 8.8 M10X16 ZINC.
2
27
165109KEB0
GEAR Z53 (MOLT. 540 RPM)
1
74
4026102908
SCREW TE 8.8 M10X30 ZINC.
16
165109KGB0
GEAR Z41 (MOLT. 1000 RPM)
1
75
4026103030
SCREW TE 8.8 M12X16 ZINC.
4
28
1663068400
LUBRICATION LINE OILTANK-OIL PUMP
1
76
4026121303
SCREW TCEI 8.8 M6X12 ZINC.
4
29
1663068800
LUBRICATION LINE OIL DRIPP.-HOUSING
1
77
4026121304
SCREW TCEI 8.8 M6X14 ZINC.
2
30
1663068900
LUBRICATION LINE HOUSING-FLANGE
1
78
4026121710
SCREW TCEI 8.8 M12X35 ZINC.
6
31
1663068700
LUBRICATION LINE OIL DRIPPER-FLANGE
1
79
4026121813
SCREW TCEI 8.8 M10X50 ZINC.
2
32
1663068500
DISCHARGE SHORT LUBRICATION LINE
1
80
4026135415
GRUB SCREW 14.9 M8X50 ZINC.
1
33
1663068600
DISCHARGE LONG LUBRICATION LINE
1
81
4026135504
GRUB SCREW 14.9 M10X10 ZINC.
1
34
1673001000
OIL FILTER PLUG
1
82
4026155505
SCREW TSPEI M5X10
4
35
1680609700
OIL PUMP GASKET
1
83
4026171211
STUD SCREW 8,8 M12X80 ZINC.
2
36
1680610200
MANIFOLD GASKET
2
84
4026300025
COMPENSATION RING
2
37
16807BCNB0
GEARBOX GASKET
1
85
4026305618
SELF-LOCKING NUT M12 ZINC.
2
38
16807011E0
CLAPET COVER GASKET
1
86
4026306115
SELF-LOCKING M36X3
1
39
1680707800
CONVEYOR FLANGE GASKET
1
87
4026308005
NUT M8 ZINC.
2
40
1680709700
FLANGE GASKET
1
88
4026308006
NUT M10 ZINC.
3
41
1680712200
PUMP HOUSING GASKET
2
89
4026350503
WASHER GROWER 6 ZINC.
4
42
1680710000
FLANGE GASKET
1
90
4026350508
WASHER GROWER 12 ZINC.
6
43
1681006500
PLATE
1
91
4026350706
WASHER GROWER 8 ZINC.
21
44
1681100200
DISTRIBUTOR BRACKET
1
92
4026350708
WASHER GROWER 10 ZINC.
4
